The Jam Jar
The Jam Jar is a small light-responsive digital synthesizer made out of a couple of dollars worth of parts and housed in a jam jar.
In this video, Yann Seznec, aka The Amazing Rolo, shows it off and makes some music with it, using Ableton Live and a guitar.
Adding MIDI To A Yamaha CS01
Send to a Friend
|
Feed for this Entry |
Filed under: Keyboard Synthesizers, MIDI Controllers, MIDI Interfaces
This video documents modding a Yamaha CS01 with a Highly Liquid Midi mod.
via nathanielscott:
The kit was shipped quickly and was easy to put together. For those of you that have a CS01 and are handy with a solder iron I highly recommend the conversion.
The Amazing Synthesizer Shoe
Send to a Friend
|
Feed for this Entry |
Filed under: Electronic Instruments, Music Videos, Strange, Synthesizers
The Shoe-thesizer is a two oscillator synthesizer with a filter built into an old Converse All-Star shoe:
The synthesizer circuit is based off a circuit (WSG by Ray Wilson) which uses three schmitt triggers. One for each of the oscillators and an extra for modulation. It also uses an op-amp to make a simple, yet effective, filter.
In the tongue of the shoe, there is a piezo transducer which is set up in parallel to one of the oscillators causing the voltage to spike, giving the synthesizer some cool rhythmic sounds. There is a switch that allows you to choose one or both oscillating frequencies to be mixed in to the output. The knobs were placed where the shoe-lace holes are and the output jack was placed in the toe area. I built this circuit during my freshmen year of high school for a science fair.
Trying getting this through your next TSA security check.
Make A Wireless MIDI System
Adafruit’s Limor Fried demos a project to create an inexpensive wireless MIDI system. This could be used to hook up something like Processing/PureData/Max to a MIDI device.
You can read the details on the project at the LadyAda site.
Creepy, Dangerous Noise Thing
Not sure what you’d call this noise thing….but it looks dangerous.
via horchacha:
variable 0-12v regulated power supply for the motor w/ direction speed
6v power supply for tube heaters
150v high voltage supply
two neon lamp oscs
rf pentode tube mixer/vcf/vca
beam modulator tube trouble maker
tubes filled with photocells control
pitch of oscs, vcas and vcf
spin that disc bro
yo
